(Basic training)
การวิเคราะห์และออกแบบโครงสร้างเหล็ก
Silo Tower ด้วย Midas Gen NX 2026
การวิเคราะห์และออกแบบโครงสร้างเหล็ก
Silo Tower ด้วย Midas Gen NX 2026
📅วันศุกร์ที่ 29 พฤษภาคม พ.ศ. 2569
⏰เวลา 9.30 - 17.00 น.
📍 ชั้น 19 อาคาร SKYY9 Centre (Onsite training)
Training Content
Modeling
- Create material and section
- Generate Column Elements
- Generate Beams
- Generate wind Braces
- Complete 3–D Modeling
- Enter Structure Support Conditions
Assign Load
- Setup Load Cases
- Define Self Weight
- Define Floor Load
- Define Bin Load
- Define X-Direction DPT Wind Load
- Define Y-Direction DPT Wind Load
- Enter the status of model data input prepared using Works Tree
Analysis and Result
- Perform Structural Analysis
- Define Load Combinations
- Verify Reactions
- Displacement Contour
Design
- Define General Design Parameter
- Steel Design
- Report
- Edit section element
- Design Result
