Vikrant Vijay PartheTechnical Support Engineer, MIDAS IT
Vikrant Vijay Parthe works as a technical support engineer at Midas Research and Development Centre. He has completed a Master of Technology in Structural Engineering from SVNIT, Surat. He is having a good experience with the analysis & design of both the bridges & building structures. He has been involved in assisting users of Midas in accomplishing structural analysis and design, including both government and private organizations.
Q. How to import a file from Midas Civil NX to FEA NX
A. We can export a file from Civil NX by using the option called " Frame Section for Solid". Then we can import this file into Fea NX by using the option called "Frame to solid".
Q. How to simulate welding in FEA NX
A. We can set the contact parameters as per our requirement to simulate the welding. Refer to the following tutorial.
Download: (https://midasinfra-my.sharepoint.com/:b:/g/personal/vikrant_midasit_com/EbggSSy8Yp5IsbQgxLZYBWMBRUsSLApUAX-nfg7xhJvRug?e=ihXgja)
Q. Can we import a 3D model to FEA NX?
A. Yes, we can import the Parasolid model in FEA NX. Kindly refer to the attached tutorial link;
a stepwise procedure is given. (https://support.midasuser.com/hc/en-us/articles/49528047075097--FEA-NX-Fatigue-Analysis-of-a-Truss-Joint)
