    2025 Global FEA NX Webinar Series 2 Simulate Cracks in Reinforced Concrete Piers with Real-World Loads

    Preview ended

    Fill out the form to keep watching

    AI Summary
    • Demonstrates full 3D modeling using Parasolid geometry and detailed meshing in MIDAS FEA NX.
    • Applies smeared cracking concrete models along with embedded rebar and prestressing tendons.
    • Covers realistic load setup including self-weight, superstructure pressure, prestress, and braking force.
    • Guides interpretation of 3D crack results, stress, and strain from nonlinear static analysis.
    Watch Video Now

    Your submission has been
    successfully received

    If you meet the certification criteria,
    Your Certificate of Completion will be sent to your email.
    If you need urgent support, contact us via here.
    We truly appreciate your participation!

    Open Access Has Ended

    The open access period has ended.
    If you have a MIDAS account, sign in
    and complete the access form to watch this session.

    Full access is one step away 👀

    Complete a short form to continue

    Benefit

    Presentation

    → Will receive email by submitting survey

    Takeaways for Attendees

    Import and process 3D geometry in FEA NX

    Define concrete nonlinear material models with tension/compression functions

    Model longitudinal rebar, tie beams, and prestressing tendons accurately

    Apply real-world loads including braking force and superstructure reaction

    Set up and run nonlinear static analysis with crack visualization

    Interpret 3D crack status, stress, and strain results

    Description

    This session walks you through a complete nonlinear static analysis of a reinforced concrete bridge pier using MIDAS FEA NX. You will learn how to import a 3D Parasolid model, define materials such as smeared cracking concrete and prestressing tendons, model longitudinal and transverse rebars, and apply real-world loads including braking force and prestress. The session concludes with interpretation of 3D crack results.


    Key FEA NX Features Covered

    • Full 3D modeling using Parasolid geometry
    • Smeared crack model for nonlinear concrete behavior
    • Rebar and tendon definition using embedded truss and prestress inputs
    • Load setup including self-weight, superstructure pressure, and braking force
    • Nonlinear static analysis with crack visualization in 3D
    • Step-by-step modeling, meshing, and boundary setup

    Speaker

    Dev Bharatia Technical Support Engineer MIDAS IT
    Dev holds a Master's in Structural Engineering from SVNIT Surat and has experience across bridge and building projects, covering both design and site execution. He enjoys tackling complex engineering problems and improving structural safety and efficiency. At MIDAS, he has worked with clients across the UK, Europe, SEA, India, and the US, and now focuses on supporting projects in the US and UK using MIDAS technology.
